This device is made by Elexol. The Elexol USB I/O 24 Pro. PRO-USBIO24 RL. Formally MK III is now RL and is RoHS compliant.
The USBIO24 R is the ROHS Compliant version of Elexol's previous USB I/O 24 range. The USB I/O 24 R is a low-cost integrated module for the input and/or output of digital signals from a computer system by connection to the USB port. The modules I/O Port pin out and firmware are compatible with the previous versions of the USB I/O24 modules.
RoHS Version Enhancements
Integrated Clock Circuit, Integrated EEPROM, Lower Supply Voltage, Integrated Level Converter on FIFO Interface and Control Signals and FTDIChip-ID� An application note describing this feature is available separately from the FTDI website .
This module combines the power of USB and a Ubicom SX52
- The module offers 3 x 8 bit programmable I/O ports
- Supplied firmware allows the ports to be individually pin programmed as inputs or outputs
- Firmware can be developed for this module for application specific tasks
MK III Firmware Additions
- Single I/O pin commands
- SPI interface (available on all ports.)
- Temperature interface to a DS18B20 (available on all I/O pins)
- LED Function
MK III Hardware Additions
- LED Function
- Powering Options
- Self Powered Mode
- Bus Powered Mode
