The Ether I/O 24 R is an UDP/IP controlled digital Input/Output module. The module features three 8-bit ports with 5V level signal lines. Each of the 24 lines can be independently programmed as either an input or output.  These boards are RoHS compliant.

The module connects to any Ethernet network supporting the TCP/IP protocol suite and can communicate with any point on that network. By connection with an Internet Router the device can communicate with any Internet connected device

• Supports ARP, BOOTP, DHCP, ICMP and UDP/IP Protocols
• Industry standard 10BaseT Ethernet Interface with an industry standard RJ-45 Connector
• 24 independently programmable signal lines with configurable CMOS, TTL or Schmitt Trigger thresholds and programmable pull-ups per line
• Easy connection by three 10 way box headers to suit low cost, standard IDC or Crimp connectors
• Integrated Switch Mode Voltage Regulator allows power from any 8-32V DC Power source
• User 5V 500mA output to power external Interface boards or sensors
• Compact module measures only 72mm x 72mm x 24mm
• Advanced configuration allows the modules to automatically scan the input ports and transmit changes directly to another ETHER I/O 24 module without host connection or to any Internet Port by router connection
• On board EEPROM allows all ports to power up in a user programmable state
• Programmable Fixed IP or Dynamic IP assignment from a DHCP server
• Small packet size and connectionless protocol allows for Real Time sensing and control
• Can be connected to a wireless network gateway or access point for wireless operation
• Low Power consumption only 1.1W fully operational

APPLICATIONS

• Home or Industrial Automation
• Digital Input and Output from any Networked PC
• Remote Data Acquisition and/or Alarm Monitoring by Network or Internet
• PC Controlled Machines and Distributed Machine I/O
• Remote Lighting / Power control and/or monitoring
