Matterport’s first-ever LiDAR camera, designed for speed and accuracy, both indoors and outdoors.
This advanced capture camera is ideal for digital twins allowing you even more accurate measurements and shown on our remotely controlled PTW scissor lift inspection robot.
The Pro3 camera comes with a charger (AC adapter), tripod mount, carry case, and 1-year warranty. [Robot not included.]
Camera Specs
Scanning
- LiDAR – Class 1 Laser
- Wavelength – 904nm
- Field of view – 360° H / 295° V
- Accuracy – +/- 20mm @ 10m
- Depth resolution – 100k points per second, 1.5M points per scan
- Min operating range – 0.5m
- Max operating range – Up to 100m (only available with E57)
- 3D data registration – Automatic
Imaging
- Output pano pixels – LiDAR
- Number of exposures per HDR frame – 5
- White balance – Automatic, full model
System
- Capture speed – <20 seconds per scan
- Camera boot time – <40 seconds
- Remote operation – Matterport Capture App on Apple or Android mobile devices
- Wireless communication – BLE to setup Wi-Fi connection, WiFi 802.11 5GHz communication with mobile device running Capture App
General
- Dimensions – 181mm x 161.4mm x 76mm
- Weight – 2.2kg
- Battery – >220 scans assuming continuous, consecutive scans
- Battery charge time – 2.5 hours 80% charge, 3.5 hours 100% charge
- Mounting mechanism – Quick release tripod mount; Female 3/8-16 thread
- GPS – Included
- Operating temperature – 0°C to 40°C
- Storage temperature – -20°C to 60°C
- Ingress protection – IP43
SuperDroid Robots is a licensed reseller of Matteport hardware and software.
