The Sabertooth 2×32 is a dual channel motor driver capable of supplying 32 amps to two motors, with peak currents up to 64 amps per motor. It can be operated from radio control, analog, TTL serial or USB inputs. It uses regenerative drive and braking for efficient operation. A variety of operating modes including tank style mixing and automatic calibration allow most projects to work immediately out of the box.
In addition to the standard operating modes, Sabertooth 2×32 features additional signal inputs and power outputs, as well as enhanced configuration options.
User-defined operating modes allow for custom operation, such as switching between radio control and computer-driven inputs on the fly, emergency stops or front panel control overrides.
The auxiliary power outputs can be configured to allow the Sabertooth 2×32 to operate from a power supply without a parallel battery, or automatic control of electromagnetic brakes.
When combined with the Kangaroo x2 motion control module, the Sabertooth 2×32 can be used for closed-loop position or speed control with encoder or analog feedback. The Kangaroo x2 adds precision position and speed control to the motor controller. The carefully tuned PID controller gives you the benefits of speed control without the need of advanced math and physics knowledge. For more information on the Kangaroo x2 click here.
Sabertooth has a built in 5V BEC that can provide power to a microcontroller or R/C receiver. The lithium cutoff mode allows Sabertooth to operate safely with lithium ion and lithium polymer battery packs – the highest energy density batteries available.
The state of the driver can be monitored in real time using the USB port in any operating mode, making debugging your project faster and easier. Sabertooth 2×32 is more flexible, robust and powerful than previous motor drivers, while also being easier to use.
