HRLV-MaxSonar-EZ3 Ultrasonic Range Finder
Component Overview
- Cost-effective solution where precision range-findings are needed
- Sensor component allows users to lower the cost of their systems without sacrificing performance
- 42kHz Ultrasonic sensor measures distance to objects
- RoHS compliant
- Read from all sensor outputs: Analog Voltage, RS232 or TTL Serial, and Pulse Width
- Virtually no sensor dead zone, objects closer than 30 cm will typically range as 30 cm
- Resolution of 1 mm
- Maximum range of 5000 mm (195 inches)
- Tolerates outside noise sources
- Operates from 2.5V-5.5V
- Low 3.1mA average current requirement
- 10Hz reading rate
- Small, light weight module
- Designed for easy integration into your project or product
- Operational Temperature from -15°C to +65°C (+5°F to +149°F)
- Real-time automatic calibration (voltage, humidity, ambient noise)
- Internal temperature compensation
- Option external temperature compensation HR-MaxTemp
- Firmware filtering for better noise tolerance and clutter rejection
- Narrow beam and good side object rejection
- Best for large object detection applications
Product Documentation
The HRLV-MaxSonar-EZ3 is a narrow beam sensor with good side object rejection. The HRLV-MaxSonar-EZ3 has slightly wider beam width than the MB1043 HRLV-MaxSonar-EZ4 which makes it a good choice for when the HRLV-MaxSonar-EZ4 does not have enough sensitivity for the application.
HRLV-MaxSonar-EZ3 Ultrasonic Range Finder
- Brand: MaxBotix
- Product Code: TS-046-103
- MPN: MB1033
- Availability: This product or this version of the product is not being sold anymore.
$49.07
