High Power Polymer Li-Ion Module 22.2V 10Ah
Features and Specifications
- Li-ion polymer
- 22.2V nominal output voltage, 25.2 Vpeak and 15 Vcutoff
- 10,000 mAh capacity, 222 Wh
- 50 Amp maximum drain current
- Built in circuit protection module
- Output wires gauged to 20 AWG with a total length of 6 inches
- 160 mm (6.3") L x 76 mm (3.0") W x 72 mm (2.8") H
- 3.3 lb (1496g)
Documentation and Support
Warning
All Lithium Batteries have shipping restrictions and typically can NOT be shipped via air (which includes overseas, second day, next day, etc.). Please review our Battery Terms for details.
Option for air shipping will still appear at checkout but we are unable to honor it.
- Please note that this battery is for R&D use only and NOT for individual customers. We are not responsible for any damages or losses caused by using this battery pack.
- Please never discharge the battery pack beyond its maximum current ratings.
- Must read before placing an order. We reserve the right to not sell the battery to any one cannot handle Li-ion batteries safely. Inappropriate use can cause serious injury or death.
- For safety warnings please visit this link
22.2V 10,000 mAh high power polymer Li-ion module. The battery has six cells and a maximum drain capacbility of 50 Amps. For use with our 1.5A Smart Li-ion battery charger (TE-120-222).
High Power Polymer Li-Ion Module 22.2V 10Ah
- Product Code: TE-119-222
- Availability: Discontinued
